Enquire NowThe height can be varied when working with different index centers, while the angle of inclination can be changed for various machining applications. In addition, the tip of the center is finely rotatable. Clamping is made by tighting of bolts.
| Ordering No. | Center Height Maximum | Center Height Minimum | Suitable for | ||
|---|---|---|---|---|---|
| Inch | mm | Inch | mm | ||
| 111301 | 6.1/4 | 108 | 3.3/16 | 80 | 110242, 110239, 110241 |
| 110247 | 8 | 200 | 4.3/4 | 120 | 110243, 110244 |
| 110248 | 8.3/8 | 210 | 6.3/8 | 160 | 110245 |
| 111304 | 3.3/8 | 85 | 1.1/2 | 38 | 111300, 111305, 111310, 110239, 110275, 110280 |
| 111311 | 3.3/8 | 85 | 1.1/2 | 38 | 111300, 111305, 111310, 110239, 110275, 110280 |
