Enquire NowT Bar clamps average clamping force of 1000kg (2200lbs). The drilled feet in the fixed head enable the clamp to be mounted to a workbench. The ductile head and slide are unbreakable, whilst the steel bar offers maximum tensile and yield strength. The slightly tapered jaws enable parallel clamping and the fast action rolled thread supplies pressure quickly and smoothly to the workspace.
| Order No. | Bar Length | Capacity | ||
|---|---|---|---|---|
| Inches | mm | Inches | mm | |
| 112258 | 30" | 750 | 24" | 600 |
| 112260 | 36" | 900 | 30" | 750 |
| 112262 | 42" | 1066 | 36" | 900 |
| 112265 | 48" | 1200 | 42" | 1066 |
| 112270 | 60" | 1500 | 54" | 1350 |
| 112275 | 72" | 1800 | 66" | 1650 |
| 112280 | 84" | 2100 | 78" | 1980 |
| 112285 | 90" | 2250 | 84" | 2100 |
