Enquire NowSwivel angle attachment is removable and can be used as a plain vise. Comes complete with removable jig plates for grinding and milling.
| Ordering No. | Length | Width | Height | Jaw Width | Jaw Opening | Jaw Depth | Net Weight Kgs. |
||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | ||
| 110091 | 5.1/2 | 140 | 5.1/4 | 133 | 3.3/4 | 95 | 2.3/4 | 70 | 1 | 26 | 1.1/4 | 32 | 3.50 |
| 110092 | 4.5/8 | 118 | 4.3/4 | 120 | 3.3/4 | 95 | 2.3/4 | 70 | 1/2 | 13 | 1.1/8 | 28 | 2.60 |
