Enquire NowAngle Plates provide a practical means for clamping and holding work in vertical position for layout, tooling and machining. Angle Plates are also used as a vertical reference for inspection and tooling purposes. They make an ideal fixture for shaping, planning, milling, grinding, drilling and boring operations.
Angle Plates are webbed AS WELL AS OPEN ENDED and provided with cored slots on both working faces to facilitate clamping. Made from close grained plain cast iron . Castings stress relieved. Hand scraped surface finish for Greater accuracy. Vertical face is of T-slotted Angle Plates provided with horizontal machined T-Slots and the base / table face is having cored slots. Precision ground flat and square. Acurracy of 0.0004†per 6†length ( 0.01mm per 150mm length ).
| Ordering No. Webbed End |
Ordering No. Open End |
Overall Length | Overall Width | Overall Height | Net Weight Kgs. |
|||
|---|---|---|---|---|---|---|---|---|
| Inch | mm | Inch | mm | Inch | mm | |||
| 110460 | 110465 | 3.1/2 | 87 | 3 | 75 | 2.1/2 | 62 | 1.20 |
| 110470 | 110475 | 4.7/16 | 111 | 3.1/2 | 87 | 3 | 75 | 1.60 |
| 110480 | 110485 | 6 | 150 | 5 | 125 | 4.1/2 | 112 | 4.50 |
| 110490 | 110495 | 8 | 200 | 6 | 150 | 5 | 125 | 7.00 |
| 110500 | 110505 | 10 | 250 | 8 | 200 | 6 | 150 | 15.00 |
| 110510 | 110515 | 12 | 300 | 9 | 225 | 8 | 200 | 24.50 |
